Avaya IP500 Universal PRI 2 Daughter Card (700417462)

Avaya IP500 Universal PRI 2 Features

• Daughter board that installs on IP500 base card
• Ports/Channels - 2 PRI trunk port. Connections via port 9 of the host IP500 base card.
• Supports the following PRI modes:
• T1 robbed bit (24B channels per port) T1 PRI (23B+D channels per port)
• E1 PRI (30B+D channels per port)
• E1R2 PRI (30B channels per port)
• Initially supports 8 unlicensed B-channels on each port
• Additional channels are activated by IP500 Universal PRI licenses
• Maximum - 4 per IP500 control unit

Compatibility

Compatible with Avaya IP500 Digital Station 8, IP500 Combination ATM, IP500 VCM 32/64, IP500 Analog Phone 2/8 Compatible with IP Office R4.1 or higher
