DA40T 40W Tabletop Mixer-Amplifier 70V/100V
DA40T 40W Tabletop Mixer-Amplifier 70V/100V
The DA40T is a versatile model in the lineup of Dayton Audio commercial mixer-amps, ideal for small to medium jobs, adding an extra zone, or basically anywhere a larger amp is not needed. The DA40T provides 40 watts of power for speakers which can be 70V, 100V, or 4 - 16 ohm speakers. Four inputs allow for two microphones, line level (BGM), and telephone paging with level controls for each input on the front panel. Bass and treble controls and Master volume are also present, so you can tailor the response to suit your specific needs. Priority muting temporarily "ducks" your background music (BGM) or other material when the Mic 1 input or the telephone input receives signal. For Mic 1, the level of reduction is adjustable from 0 - 20 dB. The Mic 1 input also offers +48V phantom power, which may be engaged or disengaged as needed. Line output is delivered via RCA jacks to feed signal to outboard equipment such as a recorder or additional zone amplifier. Dayton Audios new commercial mixer-amps have a no-nonsense design for easy installation and use, and several power levels to choose from, so youre sure to find one that meets your needs. Features like 70V/100V or 4 - 16 ohm output and mic/telephone priority muting provide maximum flexibility. And, with the same uncompromising standards of quality and value youve come to expect from Dayton Audio, you know it will be sounding great for years to come.
Features:
- Maximum power output: 40W (1% THD)
- Speaker output: 70V, 100V, 4 -16 ohm (mono, not to be used with mixed impedance loads)
- Frequency response: 80 - 16,000 Hz
- Mic input sensitivity/impedance: 5 mV, 1000 ohms
- Aux input sensitivity/impedance: 350mV, 10k ohms
- Tel input sensitivity/impedance: 350mV, 10k ohms
- Phantom power: +48V, switchable
- Power input: 110 VAC, 60 Hz
- Maximum power consumption: 70W
- Dimensions: 10.87" x 9.65 x 2.76" (276 x 245 x 70 mm)
